Pall — USA · Power Generation
HC7500SRP4Z Supralon spin-on filter element, 5 µm
Entry Two Resources is an official channel partner of Pall (Malaysia) Sdn. Bhd., specialising in asset protection filtration for the oil & gas and power generation industries.
Overview
Pall HC7500SRP4Z
A Supralon spin-on element for Pall’s 7500 Series spin-on housing: glass-fibre medium rated 5 µm at βx(c) ≥ 2000, in the 4-inch length. The 7500 housing takes flows to 325 L/min, so this is the spin-on for the larger auxiliary lube and hydraulic skids.
Elements in this family serve turbine lube oil and EHC control-fluid systems, reservoir breathers and process duties across gas-fired, coal-fired and combined-cycle plant — the part numbers we move most often for the power generation industry in Malaysia.
Current Pall part number
This is already a current Supralon part number — the successor to the older Ultipor III and Coralon HC7500 elements.
Ultipor III and Coralon replaced by Supralon — what changed →Specifications
Pall HC7500SRP4Z specification
Taken from Pall’s own published data — each value is numbered to the document it came from. Anything not listed is confirmed against your housing and duty when you enquire.
| Series | Supralon spin-on, standard medium, 7500 family[1][2] |
|---|---|
| Filtration rating | 5 µm, βx(c) ≥ 2000 (ISO 16889)[3] |
| Filter medium | Glass fibre[1] |
| Hardware | Corrosion-protected carbon steel[1] |
| Seal material | Fluorocarbon[1] |
| Nominal outside diameter | 107 mm (4.2 in)[1] |
| Nominal length | 102 mm (4 in)[1] |
| Collapse rating | 7 bar(d) / 100 psid[3] |
| Operating temperature | −29 °C to +107 °C; 60 °C maximum in water-based fluids[3] |
| Fluid compatibility | Petroleum oils and most water glycols, water-oil emulsions, and synthetic hydraulic and lube fluids[3] |
| Compatible housings | Pall 7500 Series spin-on housing (1½ in ports, to 14 bar, flows to 325 L/min)[3] |
Reading the part number
How Pall’s ordering code breaks down for HC7500SRP4Z[2].
| Code | Meaning |
|---|---|
| HC | Pall hydraulic cartridge |
| 7500 | Element family (size and housing fit) |
| S | Spin-on element |
| R | Supralon medium, standard version |
| P | Filtration grade — 5 µm, βx(c) ≥ 2000 |
| 4 | Nominal length, 4 in |
| Z | Fluorocarbon seals (standard) |
Sources
- Pall Shop — HC7500SRP4Z product listing ↗
- Pall Shop — Supralon filter elements (incl. “Understanding your Supralon part number”) ↗
- Pall — 7500/7502 Series spin-on filter datasheet (M&E7500/02EN) ↗
Product and series names are Pall’s, and the definitive datasheet for any element is the current one issued by Pall. Published values were retrieved on 30 September 2026.
Series
Supralon (replaces Ultipor III / Coralon)
Pall’s current glass-fibre lube and hydraulic elements, rated βx(c) ≥ 2000 (ISO 16889), anti-static and fitted with fluorocarbon seals as standard. The seventh character of the part number is R for standard-collapse or H for high-collapse Supralon.
Supralon replaced Coralon and Ultipor III from 1 October 2023. Send us an older HC part number and we will identify the current Supralon equivalent for you.
All Pall series we supply →Why Entry Two Resources
Buying Pall HC7500SRP4Z in Malaysia
Checked against your housing
We confirm grade, seal and collapse rating against your housing and duty before we quote, and identify the current equivalent for superseded numbers.
Power Generation
Other Pall elements in this family
