We are an official channel partner of Pall (Malaysia) Sdn. Bhd., specialising in asset protection — genuine Pall elements with traceability, not grey-market stock.
Pall — USA · Lube & Hydraulics
UE610AP40Z Athalon return-line filter element, 5 µm, 40 in
Entry Two Resources is an official channel partner of Pall (Malaysia) Sdn. Bhd., specialising in asset protection filtration for the oil & gas and power generation industries.
Overview
Pall UE610AP40Z
The 40-inch version of the Athalon 610 element: glass fibre, rated 5 µm at βx(c) ≥ 2000, for the highest-flow return-line duties. It fits the 40-inch option of Pall’s Athalon UR610 housing.
Elements in this family protect hydraulic power units, governor and control systems, gearboxes and lube circuits on rotating equipment — offshore and onshore. This is the family behind our recurring Pall supply to the power generation industry in Malaysia.
Current Pall part number
Supplied under the same part number in Pall’s current Athalon range.
Ultipleat SRT now supplied as Athalon — what changed →Specifications
Pall UE610AP40Z specification
Taken from Pall’s own published data — each value is numbered to the document it came from. Anything not listed is confirmed against your housing and duty when you enquire.
| Series | Athalon (formerly Ultipleat SRT), 610 element size[1][2] |
|---|---|
| Filtration rating | 5 µm, βx(c) ≥ 2000 (ISO 16889)[1] |
| Filter medium | Glass fibre[1] |
| Hardware | Polyacetal[1] |
| Seal material | Fluorocarbon[1] |
| Nominal outside diameter | 152 mm (6 in)[1] |
| Nominal length | 1,016 mm (40 in)[1] |
| Collapse / burst rating | 10 bar(d) / 150 psid[2][3] |
| Operating temperature | −29 °C to +120 °C with fluorocarbon seals; 60 °C maximum in water-based fluids[2] |
| Compatible housings | Pall Athalon UR610 return-line filter (40-inch length option)[2] |
Reading the part number
How Pall’s ordering code breaks down for UE610AP40Z[2].
| Code | Meaning |
|---|---|
| UE | Pall Ultipleat SRT / Athalon element |
| 610 | Element size 610 |
| AP | Filtration grade — 5 µm, βx(c) ≥ 2000 |
| 40 | Nominal length, 40 in |
| Z | Fluorocarbon seals (standard) |
Sources
- Pall Shop — UE610AP40Z product listing ↗
- Pall — Athalon™ UR610 return-line filter datasheet ↗
- Pall — Athalon™ hydraulic and lube filters brochure (M&EATHALONENa) ↗
Product and series names are Pall’s, and the definitive datasheet for any element is the current one issued by Pall. Published values were retrieved on 30 September 2026.
Series
Athalon (formerly Ultipleat SRT)
Coreless laid-over-pleat glass-fibre elements for pressure and return lines, now rated βx(c) ≥ 2000 (ISO 16889). UE210 and UE610 part numbers carried over unchanged when Pall moved the range to the Athalon name.
Send us a legacy UE part number — or a competitor’s element — and we will identify the current equivalent for you.
All Pall series we supply →Why Entry Two Resources
Buying Pall UE610AP40Z in Malaysia
Checked against your housing
We confirm grade, seal and collapse rating against your housing and duty before we quote, and identify the current equivalent for superseded numbers.
